About Jugal Shah

Jugal Shah has 19 plus years of experience in leading and managing the data and analytics practices. He has done the significant work in databases, analytics and generative AI projects. You can check his profile on http://sqldbpool.com/certificationawards/ URL.

SP_Configure

Sp_Configure procedure is used to display or change the SQL Server setting. Once you execute the SP_Configure procedure it will display the below columns in the output.

name – Name of the configuration parameter
minimum – Minimum value setting that is allowed
maximum – Maximum value that is allowed
config_value – value which currently configured
run_value – value which currently running

How to update the configuration value?
Here I will show you how to enable the XP_CmdShell using SP_Configure. Please note don’t update configuration values until you are sure, otherwise it will affect the your SQL Server performance and behavioral.

--XP_Cmdshell is an andvanced option, enbale the advanced option
EXEC sp_configure 'show advanced options', 1
GO
--Enable the advance option
RECONFIGURE
GO
--enable the xp_cmdshell
EXEC sp_configure 'xp_cmdshell', 1
GO
--Reconfigure the xp_cmdshell value
RECONFIGURE
GO

What is the difference between Config_Value and Run_Value?

When we change the Configuration Parameter value as above it will update the Config_Value filed only, but wouldn’t be in effect until you run reconfigure command. Once the reconfigure command execute or SQL Server restarted, SQL Server will run as per the new configured value.

You can get the description of the configuration parameters from books online or you can query sys.configurations and check for the description column.

select
*
from
sys.configurations

Output of the Sp_Configure

Name

Minimum Maximum Value Run Value

access check cache bucket count

0

16384

0

0

access check cache quota

0

2147483647

0

0

Ad Hoc Distributed Queries

0

1

0

0

affinity I/O mask

-2147483648

2147483647

0

0

affinity mask

-2147483648

2147483647

0

0

Agent XPs

0

1

1

1

allow updates

0

1

0

0

awe enabled

0

1

0

0

backup compression default

0

1

0

0

blocked process threshold (s)

0

86400

0

0

c2 audit mode

0

1

0

0

clr enabled

0

1

0

0

common criteria compliance enabled

0

1

0

0

cost threshold for parallelism

0

32767

5

5

cross db ownership chaining

0

1

0

0

cursor threshold

-1

2147483647

-1

-1

Database Mail XPs

0

1

0

0

default full-text language

0

2147483647

1033

1033

default language

0

9999

0

0

default trace enabled

0

1

1

1

disallow results from triggers

0

1

0

0

EKM provider enabled

0

1

0

0

filestream access level

0

2

0

0

fill factor (%)

0

100

0

0

ft crawl bandwidth (max)

0

32767

100

100

ft crawl bandwidth (min)

0

32767

0

0

ft notify bandwidth (max)

0

32767

100

100

ft notify bandwidth (min)

0

32767

0

0

index create memory (KB)

704

2147483647

0

0

in-doubt xact resolution

0

2

0

0

lightweight pooling

0

1

0

0

locks

5000

2147483647

0

0

max degree of parallelism

0

64

0

0

max full-text crawl range

0

256

4

4

max server memory (MB)

16

2147483647

2147483647

2147483647

max text repl size (B)

-1

2147483647

65536

65536

max worker threads

128

32767

0

0

media retention

0

365

0

0

min memory per query (KB)

512

2147483647

1024

1024

min server memory (MB)

0

2147483647

0

0

nested triggers

0

1

1

1

network packet size (B)

512

32767

4096

4096

Ole Automation Procedures

0

1

0

0

open objects

0

2147483647

0

0

optimize for ad hoc workloads

0

1

0

0

PH timeout (s)

1

3600

60

60

precompute rank

0

1

0

0

priority boost

0

1

0

0

query governor cost limit

0

2147483647

0

0

query wait (s)

-1

2147483647

-1

-1

recovery interval (min)

0

32767

0

0

remote access

0

1

1

1

remote admin connections

0

1

0

0

remote login timeout (s)

0

2147483647

20

20

remote proc trans

0

1

0

0

remote query timeout (s)

0

2147483647

600

600

Replication XPs

0

1

0

0

scan for startup procs

0

1

0

0

server trigger recursion

0

1

1

1

set working set size

0

1

0

0

show advanced options

0

1

1

1

SMO and DMO XPs

0

1

1

1

SQL Mail XPs

0

1

0

0

transform noise words

0

1

0

0

two digit year cutoff

1753

9999

2049

2049

user connections

0

32767

0

0

user options

0

32767

0

0

xp_cmdshell

0

1

1

1

Script to find out most CPU bound Queries

Execute below query to get TOP 25 completed queries which have the highest cumulative CPU usage

SELECT highest_cpu_queries.plan_handle,
(highest_cpu_queries.total_worker_time/highest_cpu_queries.execution_count) AS AverageCPU, highest_cpu_queries.execution_count, highest_cpu_queries.total_worker_time, highest_cpu_queries.plan_generation_num, highest_cpu_queries.creation_time, highest_cpu_queries.last_execution_time,
highest_cpu_queries.last_physical_reads, highest_cpu_queries.min_physical_reads,
q.dbid, q.objectid, q.number, q.encrypted, q.[text]
FROM (SELECT TOP 25 qs.plan_handle, qs.total_worker_time, qs.last_execution_time,
qs.plan_generation_num, qs.creation_time, qs.execution_count, qs.last_physical_reads,
qs.min_physical_reads FROM sys.dm_exec_query_stats qs
ORDER BY qs.total_worker_time DESC) AS highest_cpu_queries
CROSS APPLY sys.dm_exec_sql_text(plan_handle) AS q
ORDER BY AverageCPU DESC

Above script will return the queries which are completed. You can check the active sessions and CPU details using below query.

SELECT SPID, CPU, s2.text, open_tran, status, program_name,
net_library, loginame FROM sys.sysprocesses
CROSS APPLY sys.dm_exec_sql_text(sql_handle) AS s2
where cpu > 5000 and status = 'runnable'

How to insert value into IDENTITY column?

If you will try to insert the value into Identity column you will get the one of the below error.

Error 1:
Msg 544, Level 16, State 1, Line 1
Cannot insert explicit value for identity column in table ‘Employee’ when IDENTITY_INSERT is set to OFF.

Error 2:
Error 8101 An explicit value for the identity column in table can only be specified when a column list is used and IDENTITY_INSERT is ON

Solution:
Write SET IDENTITY_INSERT table name ON before the insert script and SET IDENTITY_INSERT table name Off after insert script.

Example,

use db1

create table Employee
(
	myID int identity(100,1),
	name varchar(20)
)

insert into Employee(name) values('Jugal')

--if i will try to insert the value into Identity column it will fail
insert into Employee(myID,name) values (101,'DJ')

--you can add the data into identiy column by turning on the IDENTITY_INSERT ON

SET IDENTITY_INSERT Employee ON
	insert into Employee(myID,name) values (101,'DJ')
SET IDENTITY_INSERT Employee OFF

Performance Tuning – Wait Statistics

Many times we got a call from the business team regarding the performance issue on the database server. As a first step you can check for the blocking, if the blocking is not there. We have to check for the waits, Query is internally waiting for the resources to complete its process.

By identifying the correct wait type will give you the directions to troubleshooting issue further. You can execute below query to get the 10 wait statistics.

SELECT TOP 10
        wait_type ,
        max_wait_time_ms wait_time_ms ,
        signal_wait_time_ms ,
        wait_time_ms - signal_wait_time_ms AS resource_wait_time_ms ,
        100.0 * wait_time_ms / SUM(wait_time_ms) OVER ( )
                                    AS percent_total_waits ,
        100.0 * signal_wait_time_ms / SUM(signal_wait_time_ms) OVER ( )
                                    AS percent_total_signal_waits ,
        100.0 * ( wait_time_ms - signal_wait_time_ms )
        / SUM(wait_time_ms) OVER ( ) AS percent_total_resource_waits
FROM    sys.dm_os_wait_stats
WHERE   wait_time_ms > 0
ORDER BY wait_time_ms DESC

You have to checkout for the below kind of wait statistics and troubleshoot as per the stats.

CXPACKET :Most of the time it indicates nothing more than that certain queries are executing with parallelism; CXPACKET waits in the server are not an immediate sign of problems, it may be the symptom of another problem, associated with one of the other high value wait types in the instance.

SOS_SCHEDULER_YIELD :The tasks executing in the system are yielding the scheduler, having exceeded their quantum, and are having to wait in the runnable queue for other tasks to execute. This may indicate that the server is under CPU pressure.

THREADPOOL :A task had to wait to have a worker bound to it, in order to execute.

LCK_* :These wait types indicate that blocking is occurring in the system and that sessions have had to wait to acquire a lock of a specific type, which was being held by another database session. This problem can be investigated further using, for example, the information in the sys.dm_db_index_operational_stats.

PAGEIOLATCH_*, IO_COMPLETION, WRITELOG :These waits are commonly associated with disk I/O bottlenecks, though the root cause of the problem may be, and commonly is, a poorly performing query that is consuming excessive amounts of memory in the server.

PAGELATCH_* :Non-I/O waits for latches on data pages in the buffer pool. A lot of times PAGELATCH_* waits are associated with allocation contention issues. One of the best-known allocations issues associated with PAGELATCH_* waits occurs in tempdb when the a large number of objects are being created and destroyed in tempdb and the system experiences contention on the Shared Global Allocation Map (SGAM), Global Allocation Map (GAM), and Page Free Space (PFS) pages in the tempdb database.

LATCH_* :These waits are associated with lightweight short-term synchronization objects that are used to protect access to internal caches, but not the buffer cache. These waits can indicate a range of problems, depending on the latch type. Determining the specific latch class that has the most accumulated wait time associated with it can be found by querying the sys.dm_os_latch_stats DMV.

ASYNC_NETWORK_IO :This wait is often incorrectly attributed to a network bottleneck.
